Star management industrial switch product series is rich, port configuration is flexible, products are made of high-performance industrial switching chip, with strong anti-interference performance; Industrial wide temperature design, to meet the stable and reliable operation in industrial environment; Support power redundancy backup, using private ring network redundancy, fault self-healing time is very short <20ms, effectively prevent communication interruption.
1: Support 4 100 Gigabit optical + 16 100 Gigabit electrical interface configuration
2: Support private ring network, support RSTP, compatible with STP
3: IP40 protection, EMC4 protection, 6000V lightning protection
4: Support Console, WEB management mode, support SNMPv1/v2c, support unified host computer software management
5: Support dual power supply redundant DC9~6V and single power supply AC85-264V/DC110-370V power supply
6: -40°C~+75°C working temperature to meet the requirements of harsh industrial environment applications
| Product model | ES520-4F |
| RJ45 port | 16 x 10Base-T/100Base-TX |
| Fiber optic port | 4 x 100Base-FX |
| Optical port parameters | Wavelength: 1310nm/1550nm (single-mode), 1310nm (multi-mode) Optical port type: SC/FC/ST optical interface is optional Transmission distance: 20 to 80 km optional (single mode), 2 km (multi-mode) Transmission rate: 155Mbps |
Electricity | DC: DC9~60V (support dual power redundancy, reverse connection protection) AC: AC85-264V/DC110-370V (single power supply). |
| Consumption | <12W(@24VDC) |
| Network standards | IEEE802.3、802.3u、802.3z、802.3x、802.1P、802.1Q、802.1D/W |
| Swap function | VLANs, port rate limiting, storm suppression, port aggregation, and flow control are supported |
| Redundancy technology | Support private Ring network technology, support RSTP, compatible with STP |
| Multicast technology | IGMPSnooping and static multicast are supported |
| Management & Maintenance | Support Console, WEB management, SNMPv1/v2c, unified host computer software management |
| Mode of exchange | Store-and-forward |
| Backplane bandwidth | 12.8Gbps |
| Cache size | 4.1Mbit |
| Mac address table | 8K |
Size | 160mm×74mm×122mm (excluding DIN rail and terminal block assembly size) |
| Operating temperature | -40°C～+75°C |
| EMC | IEC61000-4-2(ESD), Level4 IEC61000-4-5(Surge), Level4※ The network port supports 6KV lightning protection IEC61000-4-4(EFT), Level4 |
